主要特性和功能
200 MHz
4 個模擬通道和 8 個數字通道
8.5 英寸 WVGA 顯示屏，清晰且輕松的信號查看
1 Mpts 大容量存儲器可以捕獲更多數據
高達 50,000 波形/秒的更新速率可以讓您查看更多信號細節
全面的可升級特性支持您擴展測量功能：您可以在任意時間添加 20 MHz 函數發生器、3 位電壓表、串行觸發與分析、分段存儲器和模版測試等
免費的教育工作者資源套件能夠幫助您輕松配置教學實驗室
帶寬 200 MHz
帶寬升級 無
通道數 4 + 8
最大存儲器深度 1 Mpts
最大采樣率 2 GSa/s
顯示屏尺寸 8.5 inch
波形更新速率 200,000 wfms/s
ADC 位數 8 bits
內置儀器（可選）
20 MHz 函數發生器
5 位計數器
3 位 DVM
協議觸發和解碼 可選
操作系統 無
實時 是
選件
Software Application
MSOX2000-SGM Segmented Memory, fixed perpetual license
MSOX2000-LSS I2C and SPI Low Speed Serial Decode - installed
MSOX2000-LMT Limit Mask Testing, fixed perpetual license
MSOX2000-AMS CAN and LIN Automotive Serial Decode - installed
MSOX2000-232 用于 InfiniiVision 2000 X 系列示波器的計算機串行觸發和分析（RS232/UART）
MSOX2000-BDL SW application bundle license for 2000 X-Series, factory installed fixed perpetual license
Calibration Documentation
MSOX2000-A6J ANSI Z540-1-1994 Calibration
MSOX2000-AMG Calibration + Uncertainties + Guardbanding (Accredited)
Memory
MSOX2000-010 Memory upgrade - 1 M for 2000 X-series oscilloscopes - installed
Advanced Analysis
MSOX2000-001 WaveGen 20 MHz function generator, installed fixed perpetual license
Connectivity
MSOX2000-806 Module - GPIB
MSOX2000-805 Module - LAN/VGA
Localized Front Panel Overlays
MSOX2000-AKT Overlay - Russian
MSOX2000-ABZ Overlay - Italian
MSOX2000-ABJ Overlay - Japanese
MSOX2000-ABF Overlay - French
MSOX2000-ABE Overlay - Spanish
MSOX2000-ABD Overlay - German
MSOX2000-AB9 Overlay - Portuguese
MSOX2000-AB2 Overlay - simplified Chinese front panel
MSOX2000-AB1 Overlay - Korean front panel
MSOX2000-AB0 Overlay - Traditional Chinese front panel
MSOX2000-AKD Overlay- Polish Localization
MSOX2000-AB3 Overlay- Thai Localization
Regional Distribution Center
MSOX2000-PLG Power cord - Continental European, only for EU distributor with multiple power cord standards
